The Omron H8PS-8BFP serves as the primary H8PS Cam Positioner utilized to execute high-speed angular tracking and solid-state output switching across automated assembly and packaging platforms.

Model Suffix Structure and Part Deciphering

The nomenclature assigned to the H8PS series defines the hardware architecture, physical mounting support, and switching characteristics:

• 8: Represents 8 discrete output channels for angular position logic execution.
• B: Designates the integrated liquid crystal display with backlighting support.
• F: Indicates dual mounting compatibility (DIN rail mounting along with standard flush panel mounting).
• P: Identifies positive logic PNP open-collector output transistor switches.

Technical Data Specifications

Deterministic Architecture and Bus Independent Execution

The H8PS-8BFP executes real-time angle comparisons directly inside dedicated hardware logic, completely bypassing external programmable controller scan intervals. Operating independently of central CPU firmware flash compatibility and backplane bus communication velocity limits, the controller maintains consistent microsecond response times. This dedicated hardware execution guarantees precise output timing without adding processing overhead or jitter to high-speed determinism across industrial Profinet or EtherNet/IP networks.

Package Contents

• 1 x Omron H8PS-8BFP Cam Positioner Unit
• 1 x Flush Mounting Panel Adapter Kit
• 1 x Operating Instructions Sheet

Panel and DIN Rail Installation Procedures

Mechanical Enclosure Mounting

• For panel installation, make a standard 92 x 92 mm cutout, push the controller through from the front, and clamp it from behind using the panel adapter.
• For DIN rail installation, snap the rear mounting clip directly onto a standard 35 mm DIN rail until the locking latch engages fully.

Electrical Input Wiring

• Set the rotational direction DIP switch to match the mechanical coupling direction (CW or CCW) before powering on.
• Route the absolute encoder cable away from high-voltage AC motor lines to prevent inductive noise coupling.
• Terminate the cable shield to the functional ground terminal to guarantee signal integrity.

Frequently Asked Questions

• What primary power supply voltage range does the H8PS-8BFP require?

  The controller operates from an AC line voltage source between 20.4 VAC and 26.4 VAC at 50/60 Hz.

• How many switching outputs are provided on this model?

  This unit features 8 PNP open-collector transistor outputs designed to switch external industrial control loads.

• Is the display readable in low-light industrial control panels?

  Yes, the integrated liquid crystal display includes an internal backlight to provide clear visual reading in dark spaces.

• Can the unit be mounted inside a panel without cutting a square opening?

  Yes, the "F" variant hardware supports standard 35 mm DIN rail mounting as well as flush panel cutout mounting.

• How is the rotational orientation of the encoder signal switched?

  An onboard DIP switch toggles position calculations between clockwise (CW) and counterclockwise (CCW) rotation modes.

• Does controller response speed depend on main PLC backplane communication cycles?

  No, hardware angle calculations occur locally, bypassing backplane bus speed constraints and main CPU scan delays.

• What measures should be taken to ground the input encoder lines?

  Connect the shield of the encoder cable directly to the functional ground terminal and run it in a separate metal conduit.

• What panel opening size is needed for flush mounting?

  The device fits a standard 1/4 DIN cutout measuring 92 x 92 mm, with outer face dimensions of 96 x 121.2 mm.
