Configured for high-speed digital switching execution in NX I/O Bus architectures, the Omron NX-OD2258 (NX-OD2258 Digital Output Unit) provides direct physical/electrical execution.

Architectural Designation & Cataloging

• Module Classification: Digital Output Unit
• Base Catalog Code: NX-OD2258
• Bus Integration: NX I/O Bus
• Manufacturer Identity: Omron Corporation

Hardware Specifications

Industrial Controller Platform Integration

Integrated within modular automation networks, the unit interfaces directly through the proprietary high-speed backplane architecture of the Omron machine control ecosystem. The deterministic bus execution guarantees millisecond-level reaction times across distributed node topologies. Signal processing protocols manage internal synchronization frames to align actuation cycles with local controller timebases, reducing phase errors during multi-axis coordinate execution or high-rate sorting tasks.

Ordering Information

• 1 x NX-OD2258 Digital Output Module
• 1 x Integrated Push-In Connector
• 1 x Safety and Technical Instruction Sheet

Physical Deployment Directives

• Mount the module exclusively onto a DIN rail conforming to IEC 60715 dimensions using the integrated side-locking mechanism until an audible click confirms physical engagement.
• Ensure minimum vertical and horizontal clearances of 30 mm above and below the chassis enclosure to maintain convective thermal dissipation across operational limits.
• Strip field conductors to a length of 9 mm and insert directly into the push-in spring clamp terminals without ferrules to preserve low-resistance electrical contact.
• Route low-voltage output signal wiring through dedicated metallic cable trays separated from high-voltage AC power trunk lines by at least 100 mm to suppress electromagnetic interference.

Technical Inquiry Resolutions

• What is the maximum switching frequency supported by the transistor outputs?

  The module handles discrete update loops up to the hardware switching threshold defined by the 0-0.3 ms delay parameter.

• Are the outputs protected against external inductive load kickback?

  Internal freewheeling diode protection circuits absorb reverse electromotive force transients generated by inductive actuators connected to the PNP channels.

• What type of wire gauge is compatible with the push-in terminal block?

  The connector accepts solid conductors and stranded wires ranging from 0.14 mm square to 1.5 mm square without specialized crimping tools.

• Does the unit support hot-swapping during active controller operation?

  System power must be isolated prior to physical insertion or extraction of the module from the NX bus backplane to prevent bus communication corruption.

• How is module power supplied across the backplane?

  Internal logic power and field supply potentials are routed via the built-in power-supply paths of the modular DIN rail bus connectors.

• What is the function of the high-speed timestamp feature?

  The hardware logs exact microsecond transition epochs for event sequence analysis and deterministic motion synchronization across the master controller.

• Is external fusing required for the transistor output channels?

  Although internal short-circuit protection exists, external fast-blow fuses rated below the 0.5 A channel limit are recommended to protect field wiring.

• What is the enclosure ingress protection rating of the assembly?

  The mounted hardware maintains an IP20 rating, requiring installation inside a sealed electrical control cabinet to prevent particulate and moisture ingress.
